Series 30XL Low Pressure Long Drum Air Clutch

Name: Series 30XL Low Pressure Long Drum Air Clutch
Brand: Warn
SKU: W3680510
Price: 8600.0 USD
Availability: OutOfStock

PART NUMBER: 80510

This product isn't available for purchase online, please contact
WARN customer service to find a dealer.

California Prop 65:

Description

For heavy duty Winching needs, Warn Winch is a champion workhorse. Big torque, power and quick no load retrieval speed is what Warn delivers

Line Speed At Max Pull	14.9 Feet Per Minute At 30000 Pound
Mounting Pattern Size	18-1/2 Inch Length X 7-1/2 Inch Width
Estimated Install Time (Hours)	2
Winch Rating	30000 Pound
Gear Reduction Ratio	36:1
Mounting Hole Quantity	8
Color	Black
Mount Type	Fixed Mount
Universality	Fully Universal
Operation Type	Hydraulic
Recommended Use	Industrial
Free Spooling	No
Includes Mounting Hardware	No
Thermal Shutoff	No
Electrical Control Type	Not Applicable
Motor Horsepower	Not Applicable
Voltage	Not Applicable
Drive Gear Type	Planetary
Brake Type	Spring Applied Disc
Fairlead Type	Without Fairlead
Remote Type	Without Remote
Line Diameter (IN)	Without Rope
Line Length (FT)	Without Rope
Line Material	Without Rope
